Geospatial Metadata

Here are the FGDC Sections.

  1. Identification Information (1.0)
    1. Citation (1.1) (See Section 8, Citation Information)
    2. Description (1.2)
      1. Abstract (1.2.1)
      2. Purpose (1.2.2)
      3. Supplemental Information (1.2.3)
    3. Time Period of Content (1.3)
      1. Currentness Reference (1.3.1)
        • ground condition
        • publication date
        • free text
    4. Status (1.4)
      1. Progress (1.4.1)
        • Complete
        • In Work
        • Planned
      2. Maintenance and Update Frequency (1.4.2)
        • Continually
        • Daily
        • Weekly
        • Montly
        • Annually
        • Unknown
        • As needed
        • Irregular
        • None planned
        • free text
    5. Spatial Domain (1.5)
      1. Bounding Coordinates (1.5.1)
        1. West Bounding Coordinate (1.5.1.1) Domain: -180.0 <= West Bounding Coordinate <= 180.0.
        2. East Bounding Coordinate (1.5.1.2) Domain: -180.0 <= East Bounding Coordinate <= 180.0.
        3. North Bounding Coordinate (1.5.1.3) Domain: -90.0 <= North Bounding Coordinate <= 90.0.
        4. South Bounding Coordinate (1.5.1.4) Domain: -90.0 <= South Bounding Coordinate <= 90.0.
      2. Data Set G-Polygon (1.5.2)
        1. Data Set G-Polygon Outer G-Ring (1.5.2.1)
          1. G-Ring Point (1.5.2.1.1)
            1. G-Ring Latitude (1.5.2.1.1.1) Domain: -90.0 <= G-Ring Latitude <= 90.0.
            2. G-Ring Longitude (1.5.2.1.1.2) Domain: -180.0 <= G-Ring Longitude <= 180.0.
          2. G-Ring (1.5.2.1.2)
            • -90 < Latitude_elements < 90,
            • -180 < Longitude_Elements < 180
        2. Data Set G-Polygon Exclusion G-Ring (1.5.2.2)
    6. Keywords (1.6)
      1. Theme (1.6.1)
        1. Theme Keyword Thesaurus (1.6.1.1)
          • None
          • free text
        2. Theme Keyword (1.6.1.2)
      2. Place (1.6.2)
        1. Place Keyword Thesaurus (1.6.2.1)
          • None
          • Geographic Names Information System
          • free text
        2. Place Keyword (1.6.2.2)
      3. Stratum (1.6.3)
        1. Stratum Keyword Thesaurus (1.6.3.1)
          • None
          • free text
        2. Stratum Keyword (1.6.3.2)
      4. Temporal (1.6.4)
        1. Temporal Keyword Thesarus (1.6.4.1)
          • None
          • free text
        2. Temporal Keyword (1.6.4.2)
    7. Access Constraints (1.7)
      • None
      • free text
    8. Use Constraints (1.8)
      • None
      • free text
    9. Point of Contact (1.9)
    10. Browse Graphic (1.10)
      1. Browse Graphic File Name (1.10.1)
      2. Browse Graphic File Description (1.10.2)
      3. Browse Graphic File Type (1.10.3)
        • CGM
        • EPS
        • EMF
        • GIF
        • JPEG
        • PBM
        • PS
        • TIFF
        • WMF
        • XWD
    11. Data Set Credit (1.11)
    12. Security Information (1.12)
      1. Security Classification System (1.12.1)
      2. Security Classification (1.12.2)
        • Top secret
        • Secret
        • Confidential
        • Restricted
        • Unclassified
        • Sensative
        • free text
      3. Security Handling Description (1.12.3)
    13. Native Data Set Environment (1.13)
    14. Cross Reference (1.14)
  2. Data Quality Information (2.0)
    1. Attribute Accuracy (2.1)
      1. Attribute Accuracy Report (2.1.1)
      2. Quantitative Attribute Accuracy Assessment (2.1.2)
        1. Attribute Accuracy Value (2.1.2.1)
          • Unknown
          • free text
        2. Attribute Accuracy Explanation (2.1.2.2)
    2. Logical Consistency Report (2.2)
    3. Completeness Report (2.3)
    4. Positional Accuracy (2.4)
      1. Horizontal Positional Accuracy (2.4.1)
        1. Horizontal Positional Accuracy Report (2.4.1.1)
        2. Quantitative Horizonal Positional Accuracy Report (2.4.1.2)
          1. Horizontal Positional Accuracy Value (2.4.1.2.1)
          2. Horizontal Positional Accuracy Value Explanation (2.4.1.2.2)
      2. Vertical Positional Accuracy (2.4.2)
        1. Vertical Positional Accuracy Report (2.4.2.1)
        2. Quantitative Vertical Positional Accuracy Assessment (2.4.2.2)
          1. Vertical Positional Accuracy Value (2.4.2.2.1)
          2. Vertical Positional Accuracy Value Explanation (2.4.2.2.2)
    5. Lineage (2.5)
      1. Source Information (2.5.1)
        1. Source Citation (2.5.1.1)
        2. Source Scale Denominator (2.5.1.2) Domain: Source Scale Denominator > 1.
        3. Type of Source Media (2.5.1.3)
          • paper
          • stable-based material
          • microfiche
          • microfilm
          • audiocassette
          • chart
          • filmstrip
          • transparency
          • videocassette
          • videodisc
          • videotape
          • physical model
          • computer program
          • disc
          • cartridge tape
          • magnetic tape
          • online
          • CD-ROM
          • eletronic bulletin board
          • electronic mail system
          • free text
        4. Source Time Period of Content (2.5.1.4)
          1. Source Currentness Reference (2.5.1.4.1)
            • ground condition
            • publication date
            • free text
        5. Source Citation Abbreviation (2.5.1.5)
        6. Source Contribution (2.5.1.6)
      2. Process Step (2.5.2)
        1. Process Description (2.5.2.1)
        2. Source Used Citation Abbreviation (2.5.2.2)
        3. Process Date (2.5.2.3)
          • Unknown
          • Not complete
          • free date
        4. Process Time (2.5.2.4)
        5. Source Produced Citation Abbreviation (2.5.2.5) Domain: Source Citation Abbreviations from the Source Information entries for the data set.
        6. Process Contact (2.5.2.6)
    6. Cloud Cover (2.6) Domain: 0 <= Cloud Cover <= 100, Unknown
  3. Spatail Data Organization Information (3.0)
    1. Indirect Spatial Reference (3.1)
    2. Direct Spatial Reference (3.2)
      • Point
      • Vector
      • Raster
    3. Point and Vector Object Information (3.3)
      1. SDTS Terms Description (3.3.1)
        1. SDTS Point and Vector Object Type (3.3.1.1) Domain: (The domain is from "Spatial Data Concepts," which is Chapter 2 of Part 1 in Department of Commerce, 1992, Spatial Data Transfer Standard (SDTS) (Federal Information Processing Standard 173: Washington, Department of Commerce, National Institute of Standards and Technology):
          • Point
          • Entity point
          • Label point
          • Area point
          • Node, planar graph
          • Node, network
          • String
          • Link
          • Complete chain
          • Area chain
          • Network chain, planar graph
          • Network chain, nonplanar graph
          • Circular arc, three point center
          • Elliptical arc
          • Uniform B-spline
          • Piecewise Bezier
          • Ring with mixed composition
          • Ring composed of strings
          • Ring composed of chains
          • Ring composed of arc
          • G-polygon
          • GT-polygon composed of rings
          • GT-polygon composed of chains
          • Universe polygon composed of rings
          • Universe polygon composed of chains
          • Void polygon composed of rings
          • Void polygon composed of chains
        2. Point and Vector Object Count (3.3.1.2) Domain: Point and Vector Object Count < 0.
      2. VPF Terms Description (3.3.2)
        1. VPF Topology Level (3.3.2.1) Domain: 0 <= VPF Topology Level <=0.
        2. VPF Point and Vector Object Information (3.3.2.2)
          1. VPF Point and Vector Object Type (3.3.2.2.1) Domain: The domain is from Department of Defense, 1992, Vector Product Format (MIL-STD-600006): Philadelphia, Department of Defense, Defense Printing Service Detachment Office):
            • Node
            • Edge
            • Face
            • Text
    4. Raster Object Information (3.4)
      1. Raster Object Type (3.4.1) Domain: (With the exception of "voxel", the domain is from "Spatial Data Concepts," which is chapter 2 of part 1 in Department of Commerce, 1992, Spatial Data Transfer Standard (SDTS) (Federal Information Processing Standard 173): Washington, Department of Commerce, National Institute of Standards and Technology:
        • Point
        • Pixel
        • Grid Cell
        • Voxel
      2. Row Count (3.4.2) Domain: Row Count > 0.
      3. Column Count (3.4.3) Domain: Column Count > 0.
      4. Vertical Count (3.4.4) Domain: Depth Count > 0.
  4. Spatial Reference Information (4.0)
    1. Horizontal Cooridnate System Definition (4.1)
      1. Geographic (4.1.1)
        1. Latitude Resolution (4.1.1.1) Domain: Latitude Resolution > 0.0.
        2. Longitude Resolution (4.1.1.2) Domain: Longitude Resolution > 0.0.
        3. Geographic Coordinate Units (4.1.1.3)
          • Decmial degrees
          • Decimal minutes
          • Decimal seconds
          • Degrees and decimal minutes
          • Degrees, minutes, and decimal seconds
          • Radians
          • Grads
      2. Planar (4.1.2)
        1. Map Projection (4.1.2.1)
          1. Map Projection Name (4.1.2.1.1)
            • Albers Conic Equal Area
            • Azimuthal Equidistant
            • Equidistant Conic
            • Equirectangular
            • General Vertical Near-sided Projection
            • Gnomonic
            • Lambert Azimuthal Equal Area
            • Lambert Conformal Conic
            • Mercator
            • Modified Stereographic for Alaska
            • Miller Cylindrical
            • Oblique Mercator
            • Orthographic
            • Polar Stereographic
            • Polyconic
            • Robinson
            • Sinusoidal
            • Space Oblique Mercator
            • Stereographic
            • Transverse Mercator
            • van der Griten
            • free text
          2. Albers Conical Equal Area (4.1.2.1.2)
          3. Azimuthal Equidistant (4.1.2.1.3)
          4. Equidistant Conic (4.1.2.1.4)
          5. Equirectangular (4.1.2.1.5)
          6. General Vertical Near-sided Perspective (4.1.2.1.6)
          7. Gnomonic (4.1.2.1.7)
          8. Lambert Azimuthal Equal Area (4.1.2.1.8)
          9. Lambert Conformal Conic (4.1.2.1.9)
          10. Mercator (4.1.2.1.10)
          11. Modified Stereographic for Alaska (4.1.2.1.11)
          12. Miller Cylindrical (4.1.2.1.12)
          13. Oblique Mercator (4.1.2.1.13)
          14. Orthographic (4.1.2.1.14)
          15. Polar Sterographic (4.1.2.1.15)
          16. Polyconic (4.1.2.1.16)
          17. Robinson (4.1.2.1.17)
          18. Sinusoidal (4.1.2.1.18)
          19. Space Oblique Mercator (Landsat) (4.1.2.1.19)
          20. Stereographic (4.1.2.1.20)
          21. Transverse Mercator (4.1.2.1.21)
          22. van der Grinten (4.1.2.1.22)
          23. Map Projection Parameters (4.1.2.1.23)
            1. Standard Parallel (4.1.2.1.23.1) Domain: -90.0 <= Standard Parallel <= 90.0.
            2. Longitude of Central Meridian (4.1.2.1.23.2) Domain: -180.0 <= Longitude of Central Meridian <= 180.0.
            3. Lattiude of Projection Origin (4.1.2.1.23.3) Domain: -90.0 <= Latitude of Projection Origion <= 90.0.
            4. False Easting (4.1.2.1.23.4)
            5. False Northing (4.1.2.1.23.5)
            6. Scale Factor at Equator (4.1.2.1.23.6) Domain: Scale Factor at Equator > 0.0.
            7. Height of Perspective Point Above Surface (4.1.2.1.23.7) Domain: Height Perspective Point Above Surface > 0.0.
            8. Longitude of Projection Center (4.1.2.1.23.8) Domain: -180.0 < = Longitude Projection Center <= 180.0.
            9. Latitude of Projection Center (4.1.2.1.23.9) Domain: -90.0 <= Latitude of Projection Center <= 90.0.
            10. Scale Factor at Center Line (4.1.2.1.23.10) Domain: Scale Factor at Center Line > 0.0.
            11. Oblique Line Azimuth (4.1.2.1.23.11)
              1. Azimuth Angle (4.1.2.1.23.11.1) Domain: 0.0 <= Azimuthal Angle <= 360.0.
              2. Azimuth Measure Point Longitude (4.1.2.1.23.11.2) Domain: -180.0 <= Azimuth Measure Point Longitude <= 180.0.
            12. Oblique Line Point (4.1.2.1.23.12)
              1. Oblique Line Latitude (4.1.2.1.23.12.1) Domain: -90.0 <= Oblique Line Latitude <= 90.0.
              2. Oblique Line Longitude (4.1.2.1.23.12.2) Domain: -180.0 <= Oblique Line Longitude <= 180.0.
            13. Straight Vertical Longitude from Pole (4.1.2.1.23.13) Domain: -180.0 <= Straight Vertical Longitude from Pole <= 180.0.
            14. Scale Factor at Projection Origin (4.1.2.1.23.14) Domain: Scale Factor at Projection Origin > 0.0.
            15. Landsat Number (4.1.2.1.23.15)
            16. Path Number (4.1.2.1.23.16) Domain: 0 < Path Number , 251 for Landsats 1, 2, or 3. 0 < Path Number < 233 for Landsats 4 or 5, free text.
            17. Scale Factor at Central Meridian (4.1.2.1.23.17) Domain: Scale Factor at Central Meridian > 0.0.
            18. Other Projection's Definition (4.1.2.1.23.18)
        2. Grid Coordinate System (4.1.2.2)
          1. Grid Coordinate System Name (4.1.2.2.1)
            • Universal Transverse Mercator
            • Universal Polar Stereographic
            • State Plane Coordinate System 1927
            • State Plane Coordinate System 1983
            • ARC Coordinate System
            • other grid system
          2. Universal Transverse Mercator (UTM) (4.1.2.2.2)
            1. UTM Zone Number (4.1.2.2.2.1) Domain: 1 <= UTM Zone Number <= 60 for the northern hemisphere; -60 <= UTM Zone Number <= -1 for the southern hemisphere.
          3. Universal Polar Sterographic (UPS) (4.1.2.2.3)
            1. UPS Zone Identifier (4.1.2.2.3.1)
              • A
              • B
              • Y
              • Z
          4. State Plane Coordinate System (SPCS) (4.1.2.2.4)
            1. SPCS Zone Identifier (4.1.2.2.4.1) Domain: Four-digit numeric codes for the State Plane Coordinate Systems based on the North American Datum of 1927 are found in Department of Commerce, 1986, Representation of geographic point locations for information interchange (Federal Information Processing Standard 70-1): Washington: Department of Commerce, National Institute of Standards and Technology. Codes for the State Plane Coordinate Systems based on the North American Datum of 1983 are found in Department of Commerce, 1989 (January), State Plane Coordinate System of 1983 (National Oceanic and Atmospheric Administration Manual NOS NGA 5): Silver Springs, Maryland, National Oceanic and Atmospheric Administration, National Ocean Service, Coast and Geodetic Survey.
          5. ARC Coordiante System (4.1.2.2.5)
            1. Arc System Zone Identifier (4.1.2.2.5.1) Domain: 1 <= ARC System Zone Identifier <= 18.
          6. Other Grid System's Definition (4.1.2.2.6)
        3. Local Planar (4.1.2.3)
          1. Local Planar Description (4.1.2.3.1)
          2. Local Planar Georeference Information (4.1.2.3.2)
        4. Planar Coordinate Information (4.1.2.4)
          1. Planar Coordinate Encoding Method (4.1.2.4.1)
            • coordinate pair
            • distance and bearing
            • row and column
          2. Coordinate Representation (4.1.2.4.2)
            1. Abcissa Resolution (4.1.2.4.2.1) Domain: Abscissa Resolution > 0.0.
            2. Ordinate Resolution (4.1.2.4.2.2) Domain: Ordinate Resolution > 0.0.
          3. Distance and Bearing Representation (4.1.2.4.3)
            1. Distance Resolution (4.1.2.4.3.1) Domain: Distance Resolution > 0.0.
            2. Bearing Resolution (4.1.2.4.3.2) Domain: Bearing Resolution > 0.0.
            3. Bearing Units (4.1.2.4.3.3)
              • Decimal degrees
              • Decmial minutes
              • Decimal seconds
              • Degrees and decmial minutes
              • Degrees, minutes, and decimal seconds
              • Radians
              • Grads
            4. Bearing Reference Direction (4.1.2.4.3.4)
              • North
              • South
            5. Bearing Reference Meridian (4.1.2.4.3.5)
              • Assumed
              • Grid
              • Magnetic
              • Astronomic
              • Geodetic
          4. Planar Distance Units (4.1.2.4.4)
            • meters
            • international feet
            • survey feet
            • free text
      3. Local (4.1.3)
        1. Local Description (4.1.3.1)
        2. Local Georeference Information (4.1.3.2)
      4. Geodetic Model (4.1.4)
        1. Horizontal Datum Name (4.1.4.1)
          • North American Datum of 1927
          • North American Datum of 1983
          • free text
        2. Ellipsoid Name (4.1.4.2)
          • Clarke 1866
          • Geodetic Reference System 80
          • free text
        3. Semi-major Axis (4.1.4.3) Domain: Semi-major Axis > 0.0.
        4. Denominator of Flattening Ratio (4.1.4.4) Domain: Denominator of Flatting > 0.0.
    2. Vertical Coordinate System Definition (4.2)
      1. Altitude System Definition (4.2.1)
        1. Altitude Datum Name (4.2.1.1)
          • National Geodetic Vertical Datum of 1929
          • North American Vertical Datum of 1988
        2. Altitude Resolution (4.2.1.2) Domain: Altitude Resolution > 0.0.
        3. Altitude Distance Units (4.2.1.3)
          • meters
          • feet
          • free text
        4. Altitude Encoding Method (4.2.1.4)
          • Explicit elevation coordinate included with horizontal coordinates
          • Implicit coordinate
          • Attribute values
      2. Depth System Definition (4.2.2)
        1. Depth Datum Name (4.2.2.1)
          • Local surface
          • Chart datum; datum for sounding reduction
          • Lowest astronomical tide
          • Highest astronomical tide
          • Mean low water
          • Mean high water
          • Mean sea level
          • Land survey datum
          • Mean low water springs
          • Mean high water springs
          • Mean low water neap
          • Mean high water neap
          • Mean lower low water
          • Mean lower low water springs
          • Mean higher high water
          • Mean higher low water
          • Mean lower high water
          • Spring tide
          • Tropic lower low water
          • Newp tide
          • High water
          • Higher high water
          • Low water
          • Low-water datum
          • Lowest low water
          • Lower low water
          • Lowest normal low water
          • Mean tide level
          • Indian spring low water
          • High-water full and charge
          • Low-water full and charge
          • Columbia River datum
          • Gulf Coast low water datum
          • Equatorial springs low water
          • Approximate lowest astronomical tide
          • No correction
          • free text
        2. Depth Resolution (4.2.2.2) Domain: Depth Resolution > 0.0.
        3. Depth Distance Units (4.2.2.3)
          • meters
          • feet
          • free text
        4. Depth Encoding Method (4.2.2.4)
          • Explicit depth coordinate included with horizontal coordinates
          • Attribute values
  5. Entity and Attribute Information (5.0)
    1. Detailed Description (5.1)
      1. Entity Type (5.1.1)
        1. Entity Type Label (5.1.1.1)
        2. Entity Type Definition (5.1.1.2)
        3. Entity Type Definition Source (5.1.1.3)
      2. Attribute (5.1.2)
        1. Attribute Label (5.1.2.1)
        2. Attribute Definition (5.1.2.2)
        3. Attribute Definition Source (5.1.2.3)
        4. Attribute Domain Values (5.1.2.4)
          1. Enumerated Domain (5.1.2.4.1)
            1. Enumerated Domain Value (5.1.2.4.1.1)
            2. Enumerated Domain Value Definition (5.1.2.4.1.2)
            3. Enumerated Domain Value Definition Source (5.1.2.4.1.3)
          2. Range Domain (5.1.2.4.2)
            1. Range Domain Minimum (5.1.2.4.2.1)
            2. Range Domain Maximum (5.1.2.4.2.2)
            3. Attribute Units of Measure (5.1.2.4.2.3)
            4. Attribute Measurement Resolution (5.1.2.4.2.4) Domain: Attribute Measurement Resolution > 0.0.
          3. Codeset Domain (5.1.2.4.3)
            1. Codeset Name (5.1.2.4.3.1)
            2. Codeset Source (5.1.2.4.3.2)
          4. Unrepresentable Domain (5.1.2.4.4)
        5. Beginning Date of Attribute Values (5.1.2.5)
        6. Ending Date of Attribute Values (5.1.2.6)
        7. Attribute Value Accuracy Information (5.1.2.7)
          1. Attribute Value Accuracy (5.1.2.7.1)
          2. Attribute Value Accuracy Explanation (5.1.2.7.2)
        8. Attribute Measurement Frequency (5.1.2.8)
          • Unknown
          • As needed
          • Irregular
          • None planned
          • free text
    2. Overview Description (5.2)
      1. Entity and Attribute Overview (5.2.1)
      2. Entity and Attribute Detail Citation (5.2.2)
  6. Distribution Information (6.0)
    1. Distributor (6.1)
    2. Resource Description (6.2)
    3. Distribution Liability (6.3)
    4. Standard Order Process (6.4)
      1. Non-digital Form (6.4.1)
      2. Digital Form (6.4.2)
        1. Digital Transfer Information (6.4.2.1)
          1. Format Name (6.4.2.1.1) Domain: domain values from the table below; free text.
            • ARCE (ARC/INFO Export format)
            • ARCG (ARC/INFO Generate format)
            • ASCII (ASCII file, formatted for text attributes, declared format)
            • BIL (Imagery, band interleaved by line)
            • BIP (Imagery, band interleaved by pixel)
            • BSQ (Imagery, band interleaved sequenced)
            • CDF (Common Data Format)
            • CFF (Cartographic Feature File (U.S. Forest Service))
            • COORD (User-created coordinate file, declared format)
            • DEM (Digital Elevation Model format (U.S. Geological Survey)
            • DFAD (Digital Feature Analysis Data (National Imagery and Mapping Agency)
            • DGN (Microstaton format (Intergraph Corporation))
            • DIGEST (Digital Geographic Information Exchange Standard)
            • DLG (Digital Line Graph (U.S. Geological Survey)
            • DTED (Digital Terrain Elevation Data (MIL-D-89020)
            • DWG (AutoCAD Drawing Format)
            • DX90 (Data Exchange '90)
            • DXF (AutoCAD Drawing Exchange Format)
            • IGDS (Interactive Graphic Design System format (Intergraph Coporation)
            • IGES (Initial Graphics Exchange Standard)
            • MOSS (Multiple Overlay Statistical System export file)
            • netCDF (network Common Data Format)
            • NITF (National Imagery Transfer Format)
            • RPF (Raster Produc Format (National Imagery and Mapping Agency)
            • RVC (Raster Vector Converted format (MicroImages))
            • RVF (Raster Vector Format (MicroImages))
            • SDTS (Spatial Data Transfer Standard (Federal Information Processing Standard 173))
            • SIF (Standard Interchange Format (DOD Project 2851))
            • SLF (Standard Linear Format (National Imagery and Mapping Agency))
            • TIFF (Tagged Image File Format)
            • TGRLN (Topologically Integrated Geographic Encoding and Referencing (TIGER) Line format (Bureau of the Census))
            • VPF (Vector Product Format (National Imagery and Mapping Agency))
          2. Format Version Number (6.4.2.1.2)
          3. Format Version Date (6.4.2.1.3)
          4. Format Specification (6.4.2.1.4)
          5. Format Information Content (6.4.2.1.5)
          6. File Decompression Technique (6.4.2.1.6)
            • No compression applied
            • free text
          7. Transfer Size (6.4.2.1.7) Domain: Transfer Size > 0.0
        2. Digital Transfer Option (6.4.2.2)
          1. Online Option (6.4.2.2.1)
            1. Computer Contact Information (6.4.2.2.1.1)
              1. Network Address (6.4.2.2.1.1.1)
                1. Network Resource Name (6.4.2.2.1.1.1.1)
              2. Dialup Instructions (6.4.2.2.1.1.2)
                1. Lowest BPS (6.4.2.2.1.1.2.1) Domain: Lowest BPS >= 110.
                2. Highest BPS (6.4.2.2.1.1.2.2) Domain: Highest BPS > Lowest BPS.
                3. Number DataBits (6.4.2.2.1.1.2.3) 7 <= Number DataBits <= 8.
                4. Number StopBits (6.4.2.2.1.1.2.4) Domain: 1 <= Number StopBits <= 2.
                5. Parity (6.4.2.2.1.1.2.5)
                  • None
                  • Odd
                  • Even
                  • Mark
                  • Space
                6. Compression Support (6.4.2.2.1.1.2.6)
                  • V.32
                  • V.32bis
                  • V.42
                  • V.42bis
                  • free text
                7. Dialup Telephone (6.4.2.2.1.1.2.7)
                8. Dialup File Name (6.4.2.2.1.1.2.8)
            2. Access Instructions (6.4.2.2.1.2)
            3. Online Computer and Operating System (6.4.2.2.1.3)
          2. Offline Option (6.4.2.2.2)
            1. Offline Media (6.4.2.2.2.1)
              • CD-ROM
              • 3-1/2 inch floppy disk
              • 5-1/4 inch floppy disk
              • 9-track tape
              • 4 mm cartridge tape
              • 8 mm cartridge tape
              • 1/4-inch cartridge tape
              • free text
            2. Recording Capacity (6.4.2.2.2.2)
              1. Recording Density (6.4.2.2.2.2.1) Domain: Recording Density > 0.0
              2. Recording Density Units (6.4.2.2.2.2.2)
            3. Recording Format (6.4.2.2.2.3)
              • cpio
              • tar
              • High Sierra
              • ISO 9660
              • ISO 9660 with Rock Ridge extensions
              • ISO 9660 with Apple HFS extensions
              • free text
            4. Compatibility Information (6.4.2.2.2.4)
      3. Fees (6.4.3)
      4. Ordering Instructions (6.4.4)
      5. Turnaround (6.4.5)
    5. Custom Order Process (6.5)
    6. Technical Prerequisites (6.6)
    7. Available Time Period (6.7)
  7. Metadata Reference Information (7.0)
    1. Metadata Date (7.1)
    2. Metadata Review Date (7.2)
    3. Metadata Future Review Date (7.3)
    4. Metadata Contact (7.4)
    5. Metadata Standard Name (7.5)
      • FGDC Content Standard for Digital Geospatial Metadata
      • free text
    6. Metadata Standard Version (7.6)
    7. Metadata Time Convention (7.7)
      • local time
      • local time with differential factor
      • universal time
    8. Metadata Access Constraints (7.8)
    9. Metadata Use Constraints (7.9)
    10. Metadata Security Information (7.10)
      1. Metadata Security Classification System (7.10.1)
      2. Metadata Security Classification (7.10.2)
        • Top secret
        • Secret
        • Confidential
        • Restricted
        • Unclassified
        • Sensitive
      3. Metadata Security Handling Description (7.10.3)
    11. Metadata Extension (7.11)
      1. Online Linkage (7.11.1)
      2. Profile Name (7.11.2)
  8. Citation Information (8.0) [Repeatable]
    1. Originator (8.1)
      • Unknown
      • free text
    2. Publication Date (8.2)
      • Unknown
      • Unpublished material
      • free text
    3. Publication Time (8.3)
      • Unknown
      • free text
    4. Title (8.4)
    5. Edition (8.5)
    6. Geospatial Data Presentation Form (8.6) Domain: (the listed domain is partially from pp. 88-91 in Anglo-American Committee on Cataloguing of Cartographic Materials, 1982, Cartographic materials: A manual of interpretation ofr AACR2: Chicago, American Library Association):
      • atlas
      • audio
      • diagram
      • document
      • globe
      • map
      • model
      • multimedia presentation
      • profile
      • raster digital data
      • remote-sensing image
      • section
      • spreadsheet
      • tabular digital data
      • vector digital data
      • video
      • view
      • free text
    7. Series Information (8.7)
      1. Series Name (8.7.1)
      2. Issue Identification (8.7.2)
    8. Publication Information (8.8)
      1. Publication Place (8.8.1)
      2. Publisher (8.8.2)
    9. Other Citation Detail (8.9)
    10. Online Linkage (8.10)
    11. Larger Work Citation (8.11)
  9. Time Period Information (9.0) [Repeatable]
    1. Single Date/Time (9.1)
      1. Calendar Date (9.1.1)
        • Unknown
        • free date
      2. Time of Day (9.1.2)
        • Unknown
        • free time
    2. Multiple Dates/Times (9.2)
    3. Range of Dates/Times (9.3)
      1. Beginning Date (9.3.1)
        • Unknown
        • free date
      2. Beginning Time (9.3.2)
        • Unknown
        • free time
      3. Ending Date (9.3.3)
        • Unknown
        • free date
      4. Ending Time (9.3.4)
        • Unknown
        • free time
  10. Contact Information (10.0) [Repeatable]
    1. Contact Person Primary (10.1)
      1. Contact Person (10.1.1)
      2. Contact Organization (10.1.2)
    2. Contact Orginization Primary (10.2)
    3. Contact Position (10.3)
    4. Contact Address (10.4)
      1. Address Type (10.4.1)
        • mailing
        • physical
        • mailing and physical
      2. Address (10.4.2)
      3. City (10.4.3)
      4. State or Province (10.4.4)
      5. Postal Code (10.4.5)
      6. Country (10.4.6)
    5. Contact Voice Telephone (10.5)
    6. Contact TDD/TTY Telephone (10.6)
    7. Contact Facsimile Telephone (10.7)
    8. Contact Electronic Mail Address (10.8)
    9. Hours of Service (10.9)
    10. Contact Instructions (10.10)
